Device Installation

Install-METEO

The device can be mounted on the pole using the steps shown in the image.

  • First, pass the cable through the flange, then connect the cable to the SensNode METEO-MB.
  • Secure the SensNode METEO-MB to the flange using the 6 screws that come with the box.
  • Fix the flange to the pole using the provided 4 screws, nut, washer, and lock washer.
