Physical and Environmental Characteristics

Physical Characteristics​

Physical Characteristics
Ingress ProtectionIP30
Enclosure MaterialAluminum
Dimensions102 mm x 98 mm x 26 mm
MountingDIN Rail
Physical Interface
DC Barrel Jack9 V – 36 V standard 5.5 x 2.1 mm round socket
DC Terminal Block9 V – 36 V terminal block 2x5.08 mm
WAN/LAN1x 10/100M, MDI, MDIX, 1.5kV electromagnetic isolated protection
LAN1x 10/100M, MDI, MDIX, 1.5kV electromagnetic isolated protection
RS485 Terminal BlockRS485 A, B, G terminal block 3x3.81 mm
LED IndicatorsPower, Wi-Fi, 2G/3G/4G, Signal Strength, WAN, LAN
SIM Card3 V/1.8 V SIM Card
Reset Button5 Seconds: Reset the device
Wi-Fi1x SMA-K
Cellular1x SMA-K
Grounding ScrewIt is recommended to connect the grounding wire to the grounding screw located on the product

Grounding screw installation:​

  • Remove the grounding screw and place the grounding ring of the grounding wire onto the grounding screw,
  • Tighten the grounding screw,
  • Connect the grounding wire.

PhyIF-421

LED Indicators
PWRLights up when powered
WANAfter connecting the Ethernet cable, the WAN indicator will be on and will blink during data transmission.
LANAfter connecting the Ethernet cable, the LAN indicator will be on and will blink during data transmission.
WLANThe WLAN indicator will be on during normal operation.
2GThe 2G indicator will be on when connected to the 2G network.
3GThe 3G indicator will be on when connected to the 3G network.
4GWhen connected to the 4G network, the 2G and 3G indicators will be on simultaneously.
Signal Strength1 Light: Low Signal
2 Lights: Medium Signal
3 Lights: High Signal

Environmental Characteristics​

Environmental Characteristics
TemperatureOperating Temperature-20 ºC   –   +70 ºC
Storage Temperature-40 ºC   –   +125 ºC
HumidityOperating Humidity5%   –   95%
Storage Humidity1%   –   95%
