Web Interface

How to Connect to the Device​

You can connect to the device interface using either Ethernet or Wi-Fi.

To connect to the device using Ethernet, the user's computer IP address should be reconfigured to a different address within the same IP block as the device. The default settings of the device are as follows:

IP ModeStatic IP Address
Default IP192.168.0.2
Subnet Mask255.255.255.0
Default Gateway192.168.0.1

To connect to the device using Wi-Fi, you can search for the SSID ‘MODPROBUS-XXXXXXXXXX’ (where the X parts will be the device's serial number) from a mobile device or computer. The password is the device's serial number. The modem will automatically assign an IP address to the client device. The default settings of the device are as follows:

Wi-Fi ModeAP
IP ModeStatic IP Address
Default IP192.168.4.1
Subnet Mask255.255.255.0
Default Gateway192.168.4.1

If the hardware setup and connection are successfully completed, searching for the modem's IP address (192.168.0.2 for Ethernet connection, 192.168.4.1 for Wi-Fi connection) or http://modprobus-XXXXXXXXXX.local (where the X parts will be the device's serial number) in the web browser's address bar will redirect the browser to the modem's login page.

Important: Only one client device can connect to the AP, and only one client can log into the user interface.

Usernameadmin
Passwordadmin

Login-ISM842

If the login is successful, the Status page should open.

Status-ISM842

On this screen, the status of the device can be observed. The following settings can be configured under the relevant headings in the Settings tab:

  • Device
  • RF
  • WiFi
  • Ethernet
  • Modbus
  • MQTT
  • IO
  • Date & Time
  • Firewall
  • Ping
  • Wireguard

In the Rules and Devices sections, connections of other ModProBus Modems, Modbus RTU, or Modbus TCP devices can be configured. From the Update tab, the device's firmware can be updated.
