Physical and Environmental Specifications
Physical Specifications
| Physical Characteristics | |
|---|---|
| Ingress Protection | IP30 |
| Enclosure Material | Aluminum |
| Dimensions | 125.0 mm x 103.0 mm x 45.0 mm |
| Mounting | DIN Rail |
| Physical Interface | |
|---|---|
| DC Barrel Jack | 9 V – 36 V standard 5.5 x 2.1 mm round socket |
| Wired WAN | 1x WAN/LAN, 10/100/1000 Mbps, IEEE 802.3 compliant, supports automatic MDI/MDIX, 1.5KV network isolation transformer protection |
| Wired LAN | 3x LAN, 10/100/1000 Mbps, compliant with standards, supports automatic MDI/MDIX, 1.5KV network isolation transformer protection |
| Terminal Block | V+, V-: 9 V – 36 V input |
| Rx, Tx: RS232 Communication | |
| A, B: RS485 Communication | |
| GND: Ground | |
| LED Indicators | Power, Wi-Fi, 2G/3G/4G, Signal Strength, Operation |
| SIM Card | 3 V/1.8 V SIM Card |
| Reload Button | Settings/Software Reset Button |
| Wi-Fi | 2x RP-SMA-K |
| Cellular | 4x SMA-K |
| Grounding Screw | It is recommended to connect the grounding wire to the grounding screw located on the product |
Grounding screw installation:
- Remove the grounding screw and place the grounding loop of the grounding wire onto the grounding screw,
- Tighten the grounding screw,
- Connect the grounding wire.
| LED Indicators | |
|---|---|
| PWR | Will light up if power is supplied |
| Work | The router will blink green when it is ready and functioning properly. |
| SIG | Red: Low Signal Orange: Medium Signal Green: High Signal |
| WLAN | The WLAN indicator will be on during normal operation. |
| GNSS | Used in the version with GPS. |
| NET | Red: Connected to 3G. Orange: Connected to 4G. Green: Connected to 5G. |
Environmental Specifications
| Environmental Characteristics | ||
|---|---|---|
| Temperature | Operating Temperature | -35 ºC – +75 ºC |
| Storage Temperature | -40 ºC – +125 ºC | |
| Humidity | Operating Humidity | 5% – 95% |
| Storage Humidity | 1% – 95% | |
